Securing Critical Tactical Power and Field Fuel Reserves

Atlantis Tanks recently supplied a high-performance bulk fuel storage solution for Pontrilas Training Area in Herefordshire. Designed to support remote operational readiness, our engineering team supplied a tailored 1,000 Litre Steel Bunded Oil Tank integrating our patent-pending Imperium modular architecture.

Military training grounds and remote infrastructure require flexible, ultra-reliable fuel containment systems capable of withstanding demanding field environments. To ensure long-term operational versatility and strict compliance at Pontrilas, Atlantis Tanks manufactured a turnkey bunded steel storage system complete with an elevated support stand, dedicated manway access, and modular fitting capabilities.

Engineering Specifications: 1,000L StoraFUEL System

The unit was engineered to compact, high-strength structural specifications while strictly adhering to UK environmental standards and mandates.

•

  Capacity Metrics: 1,124 Litres Nominal (1,183L Brimful / 1,063L Useable with Overfill Valve)

• Outer Dimensions: 1200mm (L) x 1200mm (W) x 1000mm (H)

• Inner Dimensions: 1064mm (L) x 1134mm (W) x 997mm (H)

• Structural Material: High-grade steel to BS EN 10025-2:2004 standards, reinforced with internal structural tank bracing

• Secondary Containment: Integrated outer bund providing 110% secondary fluid capacity for absolute environmental compliance

• Elevated Mounting Stand: Dedicated 300mm high steel tank stand measuring 1800mm (L) x 1800mm (W) x 300mm (H) finished in matching RAL 6031 NATO Green

• Defense-Grade Coating: ST2 surface preparation with a Zinfos 340WS solvent-borne anti-corrosive primer and self-priming topcoat (150-micron wet / 75-micron dry film thickness) in matte-spec RAL 6031 NATO Green

• Handling & Support: Mounted on full-length steel support bearers with heavy-duty lifting eyes engineered for secure crane placement when empty

Modular Imperium Architecture and Socket Configuration

This system features our patent-pending Imperium Technology, utilizing a modular front fittings plate that allows the tank to be easily reconfigured or retrofitted with a top lockable equipment enclosure at any point in its lifespan.

• Fill & Ventilation Assembly: 3″ fill point complete with an aluminum fill point nipple, drip cap, and retaining chain, alongside dual 2″ rear vents (tank-to-bund and bund-to-atmosphere).

• Maintenance & Access: Heavy-duty 450mm steel manway access hatch for internal inspection and maintenance.

• Port Provisions:

  • 1x 1.5″ tank socket

  • 1x 2″ tank socket

  • 1x 1.5″ bund socket

• Fuel Draw & Isolation: 1″ top suction point featuring an internal standpipe, paired with a 1″ bottom outlet equipped with an internal isolation valve and T-bar handle.

Turnkey White-Glove Delivery and Compliance

Atlantis Tanks managed the complete logistical cycle using our Premium White Glove Delivery Service. Utilizing our dedicated transport fleet equipped with HIAB crane offloading, the tank and stand were delivered, offloaded, and positioned precisely on site. Backed by our standard 10-year warranty, this installation underscores our capability to deliver modular, high-integrity fuel assets for UK defense and public sector infrastructure.

If you want to view similar custom engineering projects across the public sector, explore our commercial fuel storage case studies.
